Model

1104

1204

Overall dimension(LxWxH)

5040x2255x2860

5040x2255x2870

Wheelbase(mm)

2688

Front-wheel tread(mm)

1672-2003(1760)

Rear-wheel tread(mm)

1662-2262(1662)

Min. Ground clearance(mm)

470

Min. Turning radius(m)(not apply the brake with single side)

7.0±0.3

Gear(front/rear)

12/4

engine

Model

LR6B3-23

LR6B5-23

type

In-line,water-cooling,four stroke,direct injection,NA

power

81

88.2

Rotating speed

2300

Tire size(front/rear)

14.9-24/16.9-38

14.9-26/18.4-38

Hydraulic lift capacity(kN) 610mm from suspension point

≥20

≥24

Driving output axis type

Postposition,independent and synchronization

Driving output axis

turning speed(r/min)

540/1000,or 540/720 optional
