Model
|
LT504
|
LT554
|
|
Overall dimension(LxWxH)
|
3770X1620X2130
|
3875X1635X2145
|
|
Wheelbase(mm)
|
1990
|
2010
|
|
Front-wheel tread(mm)
|
1265
|
1265
|
|
Rear-wheel tread(mm)
|
1200~1500
|
1200~1500
|
|
Min. Ground clearance(mm)
|
330
|
330
|
|
Min. Turning radius(m)(not apply the brake with single side)
|
4.3
|
4.3
|
|
Gear(front/rear)
|
12/12
(8/4 8/8 optional)
|
12/12
(8/4 8/8 optional)
|
|
Speed range(forward/backward)
|
34.02-2.55/
29.82-2.24
|
34.02-2.55/
29.82-2.24
|
|
engine
|
Model
|
A498BT-6A
|
A4K41T55-002
|
|
type
|
In-line,water-cooling,four stroke
|
|
power
|
36.8
|
40.4
|
|
Rotating speed
|
2400
|
2400
|
|
Specific fuel consumption(g/kW·h)
|
≤245
|
≤245
|
|
Tire size(front/rear)
|
8.3-20/13.6-28
|
8.3-20 /13.6-28
|
|
Hydraulic lift capacity(kN) 610mm from suspension point
|
8.28
|
9.1
|
|
Driving output axis type
|
Postposition,semi-independent
|
|
Driving output axis
turning speed(r/min)
|
540/760,or 540/1000 optional
|
