Tractor

Parameters

Model

JM-254

Drive Type

4WD

Overall Dimensions L*W*H(mm):

3080*1440*1930

Wheel Track(mm)

Front

1100

Rear

1040-1200

Wheel Base(mm)

1833

Ground Clearance (mm)

295

Rated Traction Force(N)

5980

Construction Mass(kg)

1140

Min. Turning Radius(m)

2.80

Speed range (km/h)(Without creeper)

Forward

1.73,3.42,5.71,8.01,15.80,26.40

Reverse

1.37,6.35

Speed range (km/h)(With creeper)

Forward

0.32,0.64,1.06,1.49,2.95,4.92

Reverse

0.26,1.18

Engine

Specifications

Model

Perkins EK82517U

Type

3-cylinder, Vertical,

water cooled, 4-stroke cycle, direct injection

Rated Power(kW/hp)

18.4/25

Fuel consumption (g/kW/h)

≤235

Rated Speed(rpm)

2200

Bore ×Stroke(mm)

85×90

Total Displacement(L)

1.532

Drive

System

Clutch

Dual-Stage

Gear Box

(3+1)*2

Main Drive

One Pair of Spiral Bevel Gearing

Differential

Bevel Gear

Differential Lock

Jaw Lock

Final Transmissions

Spur Gear, External ,Gearing

Traveling

Mechanism

Tire

Front

6.00-16

Rear

9.5-24

Steering Gear

hydraulic steering

Brake

Disc type

Hydraulic

System

Lifting Capacity at 610 mm Behind Lift Point(N)

4200

3-Point Suspension

Category :I

P.T.O. Shaft

Rotating Speed(rpm)

540/1000

Spline Size

6-35 Rectangular Spline
