Items
|
Technical parameter
|
|
|
Max. hoisting weight
|
4000kg (with fork)
|
|
|
Max. lifting height
|
6250mm (to the upper face of forks)
|
|
|
Max. outreach
|
5500mm (front of tyre to fork vertical section)
|
|
|
Max. traveling speed
|
30km/h
|
|
|
Min. ground clearance
|
350mm
|
|
|
Min. turning radius
|
7250mm
|
|
|
Grade ability
|
≥20%
|
|
|
The angle of lean up/down
|
15°/25°
|
|
|
Tread
|
1900mm
|
|
|
Wheel base
|
2520mm
|
|
|
Deadweight
|
9440kg
|
|
|
Overall dimension (L×W×H) (Except the tool’s)
|
6100mm×2270mm×2650mm
|
|
| |
|
Engine
(Dongfeng Cummins)
|
Type
|
4BT3.9-C80
|
|
|
Rated power
|
60kw
|
|
| |
|
Rated speed
|
2000r/min
|
|
| |
|
Exhaust
|
3.9L
|
|
|
Tyre
|
Front wheel
|
16/70-24(14PR)
|
|
|
Rear wheel
|
10.00-20(14PR)
|
|
