Wuhan XinKai Machinery Co.,Ltd

Model

7C-1.5

7CX-1.5

Carriage dimension (mm)

2000*1000*450

2000*1000*450

Overall dimension (mm)

3000*1500*1500

3000*1500*1600

Rated weight (kg)

1500

1500

Dead weight (kg)

280

330

Specification of tire

6.50-16

6.50-16

Tipping pattern

Manual

Hydraulic dump

Matched power (hp)

12-18

12-18

Model

7C-2

7CX-2

Carriage dimension (mm)

2400*1200*450

2400*1200*450

Overall dimension (mm)

3500*1550*1880

3500*1550*1880

Loading capacity(kg)

2000

2000

Dead weight (kg)

365

470

Specification of tire

7.00-16/2

7.00-16/2

Tipping pattern

Manual

Hydraulic dump

Matched power (hp)

25-40

25-40

Model

7C-3 (mono-axle)

7CX-3 (mono-axle)

7C-3（bi-axle）

7CX-3 (bi-axle)

Carriage dimension L*W*H (mm)

3000*1600*500

3000*1600*500

3400*1700*450

3400*1700*450

Overall dimension L*W*H ( mm)

4000*1600*2000

4000*1600*2100

4700*1800*2100

4700*1800*2200

Loading capacity(KG)

3000

3000

3000

3000

Dead weight (KG)

820

900

1100

1200

Tipping pattern

Manual

Hydraulic dump

Manual

Hydraulic dump

Specifications of tire

7.50-16

7.50-16

7.00-16

7.00-16

Matched power (hp)

25-30

25-30

25-30

25-30

Model

7C-5

7CX-5

Carriage dimension L*W* H (mm)

3950*2190*550

3950*2190*550

Overall dimensions L*W*H (mm)

5550*2250*2170

5550*2250*2170

Loading capacity(kg)

5000

5000

Dead weight (kg)

2000

2300

Specification of tire

8.25-16/4

8.25-16/4

Tipping pattern

Manual

Hydraulic left and right roll-over

Matched power (hp)

40-60

40-60

Model

7C-6

7CX-6

Carriage dimension L*W* H (mm)

4500*2200*550

4500*2200*550

Overall dimensions L*W*H (mm)

6200*2300*2500

6200*2300*2600

Loading capacity (kg)

6000

6000

Dead weight (kg)

2300

2500

Specification of tire

9.00-20

9.00-20

Tipping pattern

Manual

Dump

Matched power (hp)

65

65

Model

7C-8

7CX-8

Carriage dimension L*W*H (mm)

5500*220*550

5500*220*550

Overall dimension L*W*H (mm)

7300*2100*2500

7300*2200*2500

Loading capacity (kg)

8000

8000

Dead weight (kg)

2600

2800

Specification of tire

9.00-20

9.00-20

Tipping pattern

Manual

Hydraulic dump

Matched power (hp)

80-120

80-120

Model

7C-10

7CX-10

Carriage dimension L*W*H (mm)

6000*2150*550

6000*2150*550

Overall dimension L*W*H (mm)

7800*2200*2500

7300*2200*2500

Loading capacity (kg)

10000

10000

Dead weight (kg)

2800

3000

Specification of tire

8.25-16/8

8.25-16/8

Tipping pattern

Manual

Hydraulic dump

Matched power (hp)

80-120

80-120
