Wuhan XinKai Machinery Co.,Ltd

Model

2BJ-5

Overall Dimension (mm)

1950*1100*1000

Row Spacing (mm)

300-450(adjustable)

Matched Power (hp.)

24-50

Seed Colter Boot

Shoe Colter Boot

Seeding Depth (mm)

adjustable

Furrow cover

Hanging Board cover

Linkage

Mounted three-point linkage

Type of drive

Land wheel-transmission

Working speed (km/h)

5-7

Kinds of sowing

Rape, sesame, cotton, tomato, chilli

Weight (kg)

180

Model

2BX-12

2BX-14

2BX-16

2BX-18

Dimensions LXWXHmm)

1600×2000×960

1660×2280×980

1600×2650×960

1600×2930×960

Weight(kg)

288

319

420

442

Required power (kw/hp)

11-13kw

20-35kw

22-36.8kw

25-46.5kw

15~25hp

30~50hp

40~50hp

50-60hp

Rows number of seeds & fertilizer

12

14

16

18

Basic rows spacing (mm)

160(can be adjusted )

160(can be adjusted )

220(can be adjusted )

240(can be adjusted )

Max. fertilizer rate

450-900kg/mu

kg/ha.

(can be adjusted )

Max. seeds rate

450kg/ha.

kg/ha.

(can be adjusted)

Sowing depth of seeds (fertilizer)

20-50mm
